Fig. 8

Simulated residual chlorine concentrations in the distribution network. a When the chlorine initial concentration in the distribution tank was 0.64 mg L^− 1, b When the chlorine initial concentration was 0.80 mg L^− 1, c When the chlorine initial concentration was 0.87 mg L^− 1
